DC Fan
MFD3010E
: Ø30 x 10 mm
Airflow
2.2~4.5 CFM
Speed
5000~11000 RPM
Noise
20.8~34 dB(A)
Product Specifications
| Size | : Ø30 x 10 mm |
| Voltage | 5V / 12V DC |
| Motor | Brushless DC |
| Frame | plastic PBT UL94V-0 |
| Impeller | plastic PBT UL94V-0 |
| Bearing Type | Ball Bearing / Sleeve Bearing |
| Operating Temperature | Ball Bearing: -10 ~ 70°C / Sleeve Bearing: 0 ~ 60°C |
| Life Expectancy | Ball Bearing: 50,000 hours at 25°C / Sleeve Bearing: 30,000 hours at 25°C |
Part Number & Specifications
| Model | Rated Voltage (V) | Operating Voltage Range (V) | Rated Current (A) | Input Power (W) | Speed (RPM) | Max. Airflow (CFM) | Max. Pressure (mmH₂O) | Noise (dB-A) |
|---|---|---|---|---|---|---|---|---|
| MFD3010ED05-HB | 5 | 3.5 ~ 5.5 | 0.14 | 0.72 | 9000 | 3.63 | 4.09 | 28.8 |
| MFD3010ED05-HHB | 5 | 3.5 ~ 5.5 | 0.22 | 1.08 | 11000 | 4.49 | 6.05 | 34 |
| MFD3010ED05-HHS | 5 | 3.5 ~ 5.5 | 0.22 | 1.08 | 11000 | 4.49 | 6.05 | 34 |
| MFD3010ED05-HLB | 5 | 3.5 ~ 5.5 | 0.17 | 0.84 | 10000 | 3.99 | 4.94 | 30.4 |
| MFD3010ED05-HLS | 5 | 3.5 ~ 5.5 | 0.17 | 0.84 | 10000 | 3.99 | 4.94 | 30.4 |
| MFD3010ED05-HS | 5 | 3.5 ~ 5.5 | 0.14 | 0.72 | 9000 | 3.63 | 4.09 | 28.8 |
| MFD3010ED05-LB | 5 | 3.5 ~ 5.5 | 0.05 | 0.24 | 5000 | 2.21 | 1.49 | 20.8 |
| MFD3010ED05-LHB | 5 | 3.5 ~ 5.5 | 0.1 | 0.5 | 8000 | 3.33 | 3.55 | 26.5 |
| MFD3010ED05-LHS | 5 | 3.5 ~ 5.5 | 0.1 | 0.5 | 8000 | 3.33 | 3.55 | 26.5 |
| MFD3010ED05-LMB | 5 | 3.5 ~ 5.5 | 0.07 | 0.36 | 6000 | 2.39 | 1.98 | 22.7 |
| MFD3010ED05-LMS | 5 | 3.5 ~ 5.5 | 0.07 | 0.36 | 6000 | 2.39 | 1.98 | 22.7 |
| MFD3010ED05-LS | 5 | 3.5 ~ 5.5 | 0.05 | 0.24 | 5000 | 2.21 | 1.49 | 20.8 |
| MFD3010ED05-MB | 5 | 3.5 ~ 5.5 | 0.1 | 0.48 | 7000 | 2.55 | 2.72 | 24 |
| MFD3010ED05-MS | 5 | 3.5 ~ 5.5 | 0.1 | 0.48 | 7000 | 2.55 | 2.72 | 24 |
| MFD3010ED1-HB | 12 | 7 ~ 13.8 | 0.06 | 0.72 | 9000 | 3.63 | 4.09 | 28.8 |
| MFD3010ED1-HHB | 12 | 7 ~ 13.8 | 0.09 | 1.08 | 11000 | 4.49 | 6.05 | 34 |
| MFD3010ED1-HHS | 12 | 7 ~ 13.8 | 0.09 | 1.08 | 11000 | 4.49 | 6.05 | 34 |
| MFD3010ED1-HLB | 12 | 7 ~ 13.8 | 0.07 | 0.84 | 10000 | 3.99 | 4.94 | 30.4 |
| MFD3010ED1-HLS | 12 | 7 ~ 13.8 | 0.07 | 0.84 | 10000 | 3.99 | 4.94 | 30.4 |
| MFD3010ED1-HS | 12 | 7 ~ 13.8 | 0.06 | 0.72 | 9000 | 3.63 | 4.09 | 28.8 |
| MFD3010ED1-LB | 12 | 7 ~ 13.8 | 0.02 | 0.24 | 5000 | 2.21 | 1.49 | 20.8 |
| MFD3010ED1-LHB | 12 | 7 ~ 13.8 | 0.05 | 0.6 | 8000 | 3.33 | 3.55 | 26.5 |
| MFD3010ED1-LHS | 12 | 7 ~ 13.8 | 0.05 | 0.6 | 8000 | 3.33 | 3.55 | 26.5 |
| MFD3010ED1-LMB | 12 | 7 ~ 13.8 | 0.03 | 0.36 | 6000 | 2.39 | 1.98 | 22.7 |
| MFD3010ED1-LMS | 12 | 7 ~ 13.8 | 0.03 | 0.36 | 6000 | 2.39 | 1.98 | 22.7 |
| MFD3010ED1-LS | 12 | 7 ~ 13.8 | 0.02 | 0.24 | 5000 | 2.21 | 1.49 | 20.8 |
| MFD3010ED1-MB | 12 | 7 ~ 13.8 | 0.04 | 0.48 | 7000 | 2.55 | 2.72 | 24 |
| MFD3010ED1-MS | 12 | 7 ~ 13.8 | 0.04 | 0.48 | 7000 | 2.55 | 2.72 | 24 |
