MFEB9733

model:MFEB9733

add to inquiry
category： EC FAN 、EC Blower





MFEB9733

　

Bearing system: Ball, SLEEVE

Frame: Thermoplastic PBT UL94V-0

Impeller:Thermoplastic PBT UL94V-0

Weight: 170 g

　

　

　

　

　

　

　

97X 97 X 33 mm
　



MODEL Rated Voltge Operating Voltage Range Rated Current Rated Input Power  Speed Maximun Air Flow Maximun Air Pressure Noise
PART NO. VAC VAC Amp Watt R.P.M m3/min CFM mmH2O INH2O DB-A
MFEB9733-L 220V 80~230V 0.09 4.32 3000 0.363 12.8 8.99 0.354 44.8
MFEB9733-M 0.13 6 3500 0.436 15.4 12.4 0.488 47.2
MFEB9733-H 0.17 8.16 4000 0.568 20 16.17 0.637 50.9
MFEB9733-HH 0.21 10 4500 0.637 22.5 21.43 0.844 52.5
MFEB9733-VH 0.25 12 5000 0.715 25.2 26.25 1.033 55.3

　
　

　
